GRADE B - 275W Poly 5BB Cypress

Grade B

GRADE B - 275W Poly 5BB Cypress

JAP60S-01-275-SC-DMG

£18.10 exVAT (6.6p/Wp)

Wattage Rating

275 w

Panel Height

1650 mm

Panel Width

991 mm

Panel Depth

35 mm

All Technical Specifications

Documentation

MCS Certificates – JA MCS 2025

Other Features

All Grade B Item sales are final and sold as seen. Grade B items may have minor cosmetic imperfections (e.g., scratches, blemishes, dents, etc.) that do not affect functionality. Segen makes no warranties of any kind, whether express or implied, respecting the performance, condition, suitability, merchantability, or any other quality of such items. Grade B Items are not eligible for returns, refunds, or exchange, and are exempt from the Segen RMA policy. Product images are for illustrative purposes only and actual products may vary. Purchaser understands and agrees that assertion or enforcement of any manufacturer provided warranty is Purchaser’s sole responsibility.

Technical Specifications

Segen Part No JAP60S-01-275-SC-DMG
Wattage Rating 275 w
Half Cell No
Maximum Power Current Imp 8.77 A
Maximum Power Voltage Vmp 31.34 v
Module Cell Type Polycrystalline
Number Of Cells 60
Open Circuit Voltage Voc 38.38 v
Panel Depth 35 mm
Panel Height 1650 mm
Panel Width 991 mm
Short Circuit Current Isc 9.29 A
Isc 0.050
Temperature Coefficient Pmax -0.410
Temperature Coefficient Voc -0.330
Manufacturer Part Number JAP60S-01-275-SC
Panel Performance Warranty 25 Year Linear
Warranty Years 12
