GRADE B - Tiger Neo 475Wp TOPCon N-Type Mono Black Frame with JK03

Grade B

GRADE B - Tiger Neo 475Wp TOPCon N-Type Mono Black Frame with JK03

JKM475N-60HL4-V-BF-JK03-DMG

£31.20 exVAT (6.6p/Wp)

Wattage Rating

475 w

Panel Height

1903 mm

Panel Width

1134 mm

Panel Depth

30 mm

All Technical Specifications

Other Features

All Grade B Item sales are final and sold as seen. Grade B items may have minor cosmetic imperfections (e.g., scratches, blemishes, dents, etc.) that do not affect functionality. Segen makes no warranties of any kind, whether express or implied, respecting the performance, condition, suitability, merchantability, or any other quality of such items. Grade B Items are not eligible for returns, refunds, or exchange, and are exempt from the Segen RMA policy. Product images are for illustrative purposes only and actual products may vary. Purchaser understands and agrees that assertion or enforcement of any manufacturer provided warranty is Purchaser’s sole responsibility.

Technical Specifications

Segen Part No JKM475N-60HL4-V-BF-JK03-DMG
Wattage Rating 475 w
Half Cell No
Maximum Power Current Imp 13.49 A
Maximum Power Voltage Vmp 35.21 v
Module Cell Type N-Type
Number Of Cells 144
Open Circuit Voltage Voc 42.22 v
Panel Depth 30 mm
Panel Height 1903 mm
Panel Width 1134 mm
Short Circuit Current Isc 14.07 A
Isc 0.046
Temperature Coefficient Pmax -0.300
Temperature Coefficient Voc -0.250
Manufacturer Part Number JKM475N-60HL4-V-BF-JK03
Panel Performance Warranty 30 Year Linear
Warranty Years 12
